CB Electronics XP-Relay 32 Points Digitally Controlled Analogue Relay Patchbay
Til salgs25 990 kr
Beskrivelse
CB Electronics XP-Relay(32 Point)
UP TO 16 X 16 DIGITALLY CONTROLLED FULLY ANALOGUE AUDIO RELAY PATCH BAY
CONTROL ANALOG AUDIO ROUTINGS RIGHT FROM YOUR COMPUTER WITH THE XPATCH CONTROL PROGRAM OR STANDALONE
RELAY SWITCHING FOR DIRECT CONNECTION
SEALED RELAYS MORE RELIABLE THAN OPEN PATCHBAY CONTACTS
SUITABLE FOR LOW OR HIGH LEVEL SIGNALS
ONBOARD +48v PHANTOM AVAILBLE FROM LINEAR PSU
PHANTOM PASS THROUGH WHEN ONBOARD PHANTOM DISABLED
INTEGRATION WITH XPATCH4 CONTROL SOFTWARE
CAN BE USED STANDALONE
INTEGRATE WITH THE XPATCH-32/64/96
SCALEABLE: 8 x 8, Stereo 8 x 8, 16 x 8, 16 x 16
Description
XPatch is designed to replace a physical patch bay, however the electronic versions cannot pass Phantom. It is possible to implement a smaller digitally controlled patch bay using relays. The new XP-Relay range is designed to satisfy this market and will be available in 4 sizes.
All units are housed in a 1U rack mounting box and include a 48v linear power supply with remote controllable phantom switching on every input. A configuration setting will enable/disable the phantom completely on any input(s). When Phantom is Off there is a direct connection between input and output. When Phantom is enabled there is a blocking capacitor between input and output to isolate the 48v.
Up to 4 XPatch or XP-Relay units can be controlled by the XPatch4 software which allows units to be combined in different ways including using two units as stereo pairs, for example two XP-Relay 16x16’s can be controlled as a single stereo 16x16 relay based patch panel.
The XP-Relay is designed for use switching between Microphones and Mic Amps, or passive switching in a Mastering Chain
COMBINE 2 UNITS FOR UP TO 16 x 16 STEREO
UP TO 16 X 16 DIGITALLY CONTROLLED FULLY ANALOGUE AUDIO RELAY PATCH BAY
CONTROL ANALOG AUDIO ROUTINGS RIGHT FROM YOUR COMPUTER WITH THE XPATCH CONTROL PROGRAM OR STANDALONE
RELAY SWITCHING FOR DIRECT CONNECTION
SEALED RELAYS MORE RELIABLE THAN OPEN PATCHBAY CONTACTS
SUITABLE FOR LOW OR HIGH LEVEL SIGNALS
ONBOARD +48v PHANTOM AVAILBLE FROM LINEAR PSU
PHANTOM PASS THROUGH WHEN ONBOARD PHANTOM DISABLED
INTEGRATION WITH XPATCH4 CONTROL SOFTWARE
CAN BE USED STANDALONE
INTEGRATE WITH THE XPATCH-32/64/96
SCALEABLE: 8 x 8, Stereo 8 x 8, 16 x 8, 16 x 16
Description
XPatch is designed to replace a physical patch bay, however the electronic versions cannot pass Phantom. It is possible to implement a smaller digitally controlled patch bay using relays. The new XP-Relay range is designed to satisfy this market and will be available in 4 sizes.
All units are housed in a 1U rack mounting box and include a 48v linear power supply with remote controllable phantom switching on every input. A configuration setting will enable/disable the phantom completely on any input(s). When Phantom is Off there is a direct connection between input and output. When Phantom is enabled there is a blocking capacitor between input and output to isolate the 48v.
Up to 4 XPatch or XP-Relay units can be controlled by the XPatch4 software which allows units to be combined in different ways including using two units as stereo pairs, for example two XP-Relay 16x16’s can be controlled as a single stereo 16x16 relay based patch panel.
The XP-Relay is designed for use switching between Microphones and Mic Amps, or passive switching in a Mastering Chain
COMBINE 2 UNITS FOR UP TO 16 x 16 STEREO
