Solcelleregulator Epever tracer 50A
Til salgs
Fiks ferdig
2 000 kr
Frakt fra 38 kr + Trygg betaling 154 kr
Trygg handel med Fiks ferdig
Varen sendes til deg, og du har 24 timer til å inspisere den før pengene overføres til selgeren.
Beskrivelse av varen
Tilstand: Som ny - Ikke synlig brukt
Lite brukt, selges pga oppgradering til flere paneler. Stått montert innendørs i skap.
Product features
Multi-functional LCD display with backlight
advanced MPPT technology with a tracking efficiency of at least 99.5% and a maximum efficiency of 98%
"ultra-fast" recording speed
precise detection of maximum power points (MPP) with multiple peaks
RS485 interface with MODBUS industry standards
negative ground via (-) - pole
fully programmable functions via PC software
automatic system voltage detection 12/24/36/48V
Battery deep discharge protection, overcharge protection, overvoltage protection
Full load operation without power loss in the working environment temperature range
temperature-dependent charge parameter correction (only for lead-acid battery)
battery types adjustable (open acid, AGM, gel, user)
Solar input Module open circuit voltage up to 150 V open circuit voltage
Real-time energy statistics function
comprehensive electronic protection
wide MPP operating voltage range
overheating reduction function
Monitoring and setting of parameters via the mobile phone APP or PC software possible
Technical specifications
Manufacturer modelTracer5415AN
Article number2105415
Rated voltage12/24/36 / 48VDC auto
Rated charging current50A
Discharge current50AMax.
PV open circuit voltage150V
MPP voltage range(Battery voltage + 2) ~ 108VMax.
PV input power625W / 12V, 1250W / 24V, 1875W / 36V, 2500W / 48VMax. PV Array power937.5W/12V, 1875W/24V, 2812.5W/36V, 3750W/48V
Own electricity consumption98mA / 12V, 60mA / 24V, 50mA / 36V, 46mA / 48VTemperature compensation coefficient-3mV / ° C / 2V (default)
RS485 interfaceRS485 (RJ45)Temperature range-25 ° C to + 45 ° CDegree of protectionIP20Dimensions261 * 216 * 119mmNet weight3.5Kg
