Digital Satellite Finder m/ 3,5 LCD
(1/93)
Digital Satellit Finder m/ 3,5 LCD display
Til salgs1 199 kr
Beskrivelse
Høy kvalitets Digital Satellit Finder.
The WS-6908 meter enables the user to quickly setup satellite dishes and LNBs.
With the built-in satellite receiver, the user can view on its screen specific FTA channels and assess their quality. At the design stage it helps to select the equipment (dish, LNBs, amplifiers, multiswitches) and, during implementation, to verify the choice and align the dish and LNB(s).
The WS-6908 model is the successor to WS-6906. The changes include a new, even more user-friendly menu, and implementation of bit error rate (BER) measurements. The new software allows for displaying the results of quality, BER, and other measurements on the whole screen. Additionally, the new model has a slightly more capacious battery.
The A/V inputs enable connection of CCTV cameras, making the device a very useful tool for installers of video surveillance systems. The installer can precisely set the focal length and focus of each camera and check the exposure settings.
Distinguishing features:
DVB-S measurements incl. C/N, S/N, BER,
3.5" (8.9 cm) TFT LCD color display,
Built-in FTA receiver (with color and sound),
English and Polish menus,
Sat finder function,
Automatic transponder scan,
PID & NIT search,
Blindscan function,
Sound signalling,
Built-in fan,
Accessories: holder, charger (90... 240 VAC), car charger (12 VDC), CD-ROM.
A/V input and output,
Support for DiSEqC 1.0, 1.1 and 22 kHz band switching.
Specifications
Supported standard DVB-S YES
Measuring input RF connector F
Frequency range 950... 2150 MHz
Signal level range -65...-25 dBm
LNB power 13/18V, max 400 mA
Band switching 0/22 kHz
DiSEqC 1.0, 1.1
Demodulator Modulation QPSK
Symbol rate 2... 45 Mbps
SCPC and MCPC support YES
Spectrum inversion Automatic conversion
System Processor 32 bit, 200 MHz
SDRAM 16 MB
FLASH 2 MB
EEPROM 8 KB
Video decoder MPEG 2 YES
Channel capacity up to 15 Mb/s
Resolutions 720x576, 720x480
TV systems PAL/NTSC/SECAM
MPEG Audio MPEG 1 layer 1 & 2 YES
Audio iutput mono
Sampling frequencies 32, 44.1, 48 kHz
Serial interface Connector USB
Power Li-Ion battery capacity 1.95 Ah
Supplying voltage (device) 14.5 VDC
Supplying voltage (AC charger) AC 90... 240 V
Connectors A/V IN and OUT Mini Jack
Weight With packaging 1.22 kg
The WS-6908 meter enables the user to quickly setup satellite dishes and LNBs.
With the built-in satellite receiver, the user can view on its screen specific FTA channels and assess their quality. At the design stage it helps to select the equipment (dish, LNBs, amplifiers, multiswitches) and, during implementation, to verify the choice and align the dish and LNB(s).
The WS-6908 model is the successor to WS-6906. The changes include a new, even more user-friendly menu, and implementation of bit error rate (BER) measurements. The new software allows for displaying the results of quality, BER, and other measurements on the whole screen. Additionally, the new model has a slightly more capacious battery.
The A/V inputs enable connection of CCTV cameras, making the device a very useful tool for installers of video surveillance systems. The installer can precisely set the focal length and focus of each camera and check the exposure settings.
Distinguishing features:
DVB-S measurements incl. C/N, S/N, BER,
3.5" (8.9 cm) TFT LCD color display,
Built-in FTA receiver (with color and sound),
English and Polish menus,
Sat finder function,
Automatic transponder scan,
PID & NIT search,
Blindscan function,
Sound signalling,
Built-in fan,
Accessories: holder, charger (90... 240 VAC), car charger (12 VDC), CD-ROM.
A/V input and output,
Support for DiSEqC 1.0, 1.1 and 22 kHz band switching.
Specifications
Supported standard DVB-S YES
Measuring input RF connector F
Frequency range 950... 2150 MHz
Signal level range -65...-25 dBm
LNB power 13/18V, max 400 mA
Band switching 0/22 kHz
DiSEqC 1.0, 1.1
Demodulator Modulation QPSK
Symbol rate 2... 45 Mbps
SCPC and MCPC support YES
Spectrum inversion Automatic conversion
System Processor 32 bit, 200 MHz
SDRAM 16 MB
FLASH 2 MB
EEPROM 8 KB
Video decoder MPEG 2 YES
Channel capacity up to 15 Mb/s
Resolutions 720x576, 720x480
TV systems PAL/NTSC/SECAM
MPEG Audio MPEG 1 layer 1 & 2 YES
Audio iutput mono
Sampling frequencies 32, 44.1, 48 kHz
Serial interface Connector USB
Power Li-Ion battery capacity 1.95 Ah
Supplying voltage (device) 14.5 VDC
Supplying voltage (AC charger) AC 90... 240 V
Connectors A/V IN and OUT Mini Jack
Weight With packaging 1.22 kg
