Wes Audio ng78 Next Generation Analog Stereo FET Compressor W/Digital Recall
Til salgs
Beskrivelse
Nyhet!
På lager hos oss til førjulstilbud!
Ta kontakt for tilbud!
Wes Audio NG78
Fully analog Stereo FET Compressor with digital recall
FET compressors have long shaped the character and dynamics of recordings in professional studios. The ng78 continues this tradition with a two-channel, fully analog design featuring digital recall. Each channel offers an extended attack time of up to 20 ms, enabling precise transient control while
preserving the signature speed and punch of FET compression. The newly added 2:1 ratio delivers subtle, musical compression. Introducing the ng78 – a blend of classic FET sound and modern versatility, providing full control across two channels
MAIN FEATURES SUMMARY
Core Features:
· 100% Analog Stereo FET Compressor (1176-style) with +24dBu of headroom.
· Five Ratio Settings: 2:1, 4:1, 8:1, 12:1, 20:1 – including All-Button Mode and a gentle 2:1 ratio option.
· Extended Attack Range – now starting from slower values for more natural transient control.
· Total Recall & Plug-in Control – seamless integration with most major DAWs.
· Parallel Compression via dedicated MIX knob.
· Carnhill Transformer Output Stage for added analog weight and character.
· Flexible Detector Linking – choose between dual mono stereo compression or true stereo operation.
· Saturation Mode – a dedicated control simultaneously adjusts input and output (compression circuit disabled),
turning the unit into a saturation box or clipper.
· Dynamic Link Technology – adaptive circuit that compensates for component tolerances in the sidechain signal,
ensuring perfect stereo balance during compression for every parameter combination.
Sidechain & Metering:
· Advanced Sidechain EQ with two independent sections:
· High-Pass Filter at 60 Hz / 90 Hz / 150 Hz – preserve low-end while compressing.
· High Shelf at 2 kHz / 5 kHz / 10 kHz – emphasize mid/high content for precise detection.
· 2 Vintage-Style Gain Reduction Meters for classic visual feedback.
· High-Precision Input & Output Metering for accurate level monitoring.
Additional Highlights
· Classic FET Compressor Controls: Input, Output, Attack, Release.
· Selectable THD (Total Harmonic Distortion) with Low, Mid, and High modes – tailored harmonic
enhancement from the FET circuit.
· Fully Digitally Controlled Analog Circuit – isolated control path ensures pure analog signal integrity.
· Hardware A/B Switching – instantly compare two independent settings.
· Analog Automation in DAW for modern hybrid workflows.
· USB & Ethernet Connectivity for flexible plugin integration.
· Form Factor: 2U rackmount.
SPECS:
· Attack time: 20us – 20ms,
· Release time: 50ms – 1100ms,
· Compression ratio: 2:1, 4:1, 8:1, 12:1, 20:1 (all possible combinations), · True Bypass,
· Side chain signal HPF: 60, 90, 150 Hz,
· Side chain signal High Shelf: 2, 5, 10 kHz,
· Output impedance: 50ohm,
· Frequency response: 20Hz-20kHz (+/- 1dB),
· Signal to noise ratio SNR >83dB,
· Balanced output and input,
· Case Rack: 2U,
· Power consumption: 14W,
· Dimensions: 88x483x235mm,
· Weight 7kg,
· Warranty 2 years.
På lager hos oss til førjulstilbud!
Ta kontakt for tilbud!
Wes Audio NG78
Fully analog Stereo FET Compressor with digital recall
FET compressors have long shaped the character and dynamics of recordings in professional studios. The ng78 continues this tradition with a two-channel, fully analog design featuring digital recall. Each channel offers an extended attack time of up to 20 ms, enabling precise transient control while
preserving the signature speed and punch of FET compression. The newly added 2:1 ratio delivers subtle, musical compression. Introducing the ng78 – a blend of classic FET sound and modern versatility, providing full control across two channels
MAIN FEATURES SUMMARY
Core Features:
· 100% Analog Stereo FET Compressor (1176-style) with +24dBu of headroom.
· Five Ratio Settings: 2:1, 4:1, 8:1, 12:1, 20:1 – including All-Button Mode and a gentle 2:1 ratio option.
· Extended Attack Range – now starting from slower values for more natural transient control.
· Total Recall & Plug-in Control – seamless integration with most major DAWs.
· Parallel Compression via dedicated MIX knob.
· Carnhill Transformer Output Stage for added analog weight and character.
· Flexible Detector Linking – choose between dual mono stereo compression or true stereo operation.
· Saturation Mode – a dedicated control simultaneously adjusts input and output (compression circuit disabled),
turning the unit into a saturation box or clipper.
· Dynamic Link Technology – adaptive circuit that compensates for component tolerances in the sidechain signal,
ensuring perfect stereo balance during compression for every parameter combination.
Sidechain & Metering:
· Advanced Sidechain EQ with two independent sections:
· High-Pass Filter at 60 Hz / 90 Hz / 150 Hz – preserve low-end while compressing.
· High Shelf at 2 kHz / 5 kHz / 10 kHz – emphasize mid/high content for precise detection.
· 2 Vintage-Style Gain Reduction Meters for classic visual feedback.
· High-Precision Input & Output Metering for accurate level monitoring.
Additional Highlights
· Classic FET Compressor Controls: Input, Output, Attack, Release.
· Selectable THD (Total Harmonic Distortion) with Low, Mid, and High modes – tailored harmonic
enhancement from the FET circuit.
· Fully Digitally Controlled Analog Circuit – isolated control path ensures pure analog signal integrity.
· Hardware A/B Switching – instantly compare two independent settings.
· Analog Automation in DAW for modern hybrid workflows.
· USB & Ethernet Connectivity for flexible plugin integration.
· Form Factor: 2U rackmount.
SPECS:
· Attack time: 20us – 20ms,
· Release time: 50ms – 1100ms,
· Compression ratio: 2:1, 4:1, 8:1, 12:1, 20:1 (all possible combinations), · True Bypass,
· Side chain signal HPF: 60, 90, 150 Hz,
· Side chain signal High Shelf: 2, 5, 10 kHz,
· Output impedance: 50ohm,
· Frequency response: 20Hz-20kHz (+/- 1dB),
· Signal to noise ratio SNR >83dB,
· Balanced output and input,
· Case Rack: 2U,
· Power consumption: 14W,
· Dimensions: 88x483x235mm,
· Weight 7kg,
· Warranty 2 years.
