Prism Sound Atlas m/MDIO Pro Tools HDX Digilink Option Card

Kampanje til 30 April 2024!

Prism Sound Atlas med PT HDX MDIO Option Card + Tracktion Everything Bundle.

Prism Sound Atlas med PT HDX MDIO Digilink Option Card for tilkobling til AVID Pro Tools HD/HDX systemer via Digilink port.

NB:Prism Sound Atlas Kan også brukes som vanlig USB 2 lydkort!
(The MDIO expansion slot provides an alternative host connection. It does not necessarily disable the USB port, but in the case of the Pro Tools interface MDIO-PTHDX, the USB port is switched off when the Pro Tools interface is to be used.)


Prism Sound Atlas har 8 Mic Pre/Line inn på Kombo XLR/TRS inputs,8 Line Out,ADAT I/O,2 DI innganger i front,2 Kraftige Headphones Utganger,Midi I/O,Word Clock,USB 2.


TECH SPECS
Instrument Inputs 2 x 6.3mm mono jack sockets, auto-select to analogue inputs 1 & 2 when plugged
Headphone Outputs 2 x 6.3mm stereo TRS Jacks, each with illuminated volume control
Master volume Assignable encoder / push switch with halo indication
Standby button with standby indicator (also flashes when unit is in ‘identify’ mode)
Level Meters 10 x multi-segment bargraphs with overload indication, 8 for analogue, 2 for digital, assignable to inputs or outputs
Input selection Indicate mode of analogue inputs 1-8 as Mic / line / inst with phantom power indication for mic mode
Overkiller For every analogue input, lit when Overkiller limiters are acting
Digital Input indicators for digital input unlocked and SRC (sample-rate converter) selected
Digital Output indicator for SRC (sample-rate converter) selected


Mic / Line inputs 8 x combo connectors with XLR sockets for mic input and 6.3mm TRS jack sockets for line input (balanced or unbalanced)
Line outputs 8 x 6.3mm TRS jack sockets (balanced or unbalanced)
Digital inputs 1 x RCA 1 x TOSLINK for S/PDIF or ADAT Optical input; (RCA can operate as AES3 input using XLR-RCA adapter supplied)
Digital output 1 x RCA 1 x TOSLINK for S/PDIF or ADAT Optical output; (RCA can operate as AES3 output using XLR-RCA adapter supplied)
MIDI I/O 2 x 5 Pin DIN sockets (in and out)
Wordclock 2 x BNC sockets, output and input (75R)
USB port 1 x USB 2 port

ATLAS + PT HDX MDIO Option Card!


MDIO PRO TOOLS HDX
DELIVERING THE WORLD'S GREATEST SOUND TO PRO TOOLS

Prism Sound delivers the most digitally accurate solution for recording with Pro-Tools with the MDIO-HDX card for Atlas and Titan.

The card allows multiple units to be connected directly to an AVID Pro Tools HDX or HD Native system via AVID’s “Digilink” connection delivering complete expandability. This has made Atlas and Titan the foundation of Pro-Tools systems worldwide.

The demand from professionals for ever increasing levels of performance has ensured the Prism Sound Atlas and Titan have become go to solutions for those which require more from their Pro-Tools systems.
REFERENCE GRADE EXPANDABLE PRODUCTION INTERFACE

Atlas and Titan are world class multi-track interfaces offering flexible expansion and unsurpassable sonic clarity. Using the latest generation of Prism Sounds trusted conversion, Atlas provides more preamps than Titan making it suitable for a wider range of recording scenarios.


UNSURPASSED CLOCKING AND JITTER REJECTION

Prism Sounds history in developing test and measurement equipment for the audio industry has allowed our engineers to get a much deeper understanding of digital clocking and its associated issues.


DIGITAL MIXER WITH FLEXIBLE MONITORING

Atlas has a powerful built-in digital mixer that can be configured to provide a multitude of ultra low latency feeds, Including foldback to performers, stereo and surround outputs.


MIC PREAMPS

The Atlas boasts 8 ultra-clean, low-noise microphone preamps that perfectly compliment its transparent A/D conversion (with software controllable phantom power, -20dB pad and Overkiller limiter switches on each channel.)


FUTURE PROOF CONNECTIVITY

With a standard USB connection Atlas can connect to the widest range of computers today and for the foreseeable future. Add to this the option of ProTools HDX and Dante modules for the most flexible and professional solution.
MDIO

Kampanje til 31 Mars 2024:

Få med Tracktion Everything Bundle(Verdi 12.500,-.)ved kjøp av Prism Sound USB lydkort!

Waveform 12 Pro($149 value)
DAW Essentials Collection
Collective
Autotune
Melodyne Essential
BioTek 2 ($199 value)
Sanfilippo, Testa & Lombardo Imagina drum loop libraries ($297 value)
Dan Dean Essential Bass ($99 value)
RetroMod Collection ($523 value)
F.’em ($179 value)
MOK Waverazor ($159 value)
Abyss ($129 value)
Chop Suey ($89 value)
Hyperion ($129 value)
KULT ($129 value)
Novum ($179 value)
SpaceCraft ($99 value)
All current sound packs
