Prism Sound Dream ADA-128 Dolby Atmos Modular I/O for Pro Tools HDX/DANTE

Vi kjører nå svært aggresiv prising på noen får enheter på Prism Sound sitt nye flaggskip av Pro Tools HDX Interface og AD/DA konvertere.
Prism Sound Dream ADA-128!

Nå kan vi levere Prism Sound Dream ADA-128 med 16 Analoge I/O og PTHDX kort + Dante kort til meget gode priser!


Nå med With Ginger Audio GroundControl Sphere Software
For full Dolby Atmos speaker management, routing and control room software.

I tillegg kan vi også gi inbytte rabatt på inbytte av andre Prism Sound Orpheus,Lyra,Titan,Atlas eller ADA8 interface.inbytte rabatt avhenger av hvilket interface.

Vi kan også vurdere å ta i inbytte Interface fra andre produsenter.

Ta kontakt for mer info og mulige konfiguarasjoner og inbytte muligheter!


Prism Sound ADA-128
MODULAR HIGH-QUALITY AUDIO CONVERSION SYSTEM.

Støtte for Pro Tools HDX,Dante,Standalone AD/DA,etc.
(Thunderbolt 3,Ravenna og MADI kommer senere i 2023).


Ta kontakt for mulige konfigurasjoner og tilbud!

Vi tar nå inbytte!


Mulighet for 128 Kanaler for full Dolby Atmos støtte.

16 Expansion slots,og 4 Host slots.

Tilgjengelige host cards:

ADA-128 Pro Tools HDX Option Card(2 Digilink Porter)
ADA-128 DANTE Option Card(128 kanaler begge veier)
ADA-128 8 Channel AES/EBU Option Card(8 I/O pr card)

Tilgjengelige Expansion cards:


ADA-128 8 Chn Line In AD Option Card(8 Inputs pr.card)
ADA-128 8 Chn Line Out DA Option Card(8 Outputs pr.card)
ADA-128 8 Channel AES/EBU Option Card(8 I/O pr card)

(DREAM ADA-128 MIC/LINE, RAVENNA, THUNDERBOLT AND MADI CARDS COMING SOON)


A new breed of audio converter has arrived: Prism Sound’s Dream ADA-128.

The Dream ADA-128 redefines flexibility, capacity, and performance standards in professional audio conversion. In creating it, we ripped up the rule book and started again, using all our 30+ years of ADC and DAC development experience. Building on the legacy of the Prism Sound Dream ADA-8XR, the resulting Dream ADA-128 architecture is so capable that it is set to meet the needs of the most demanding facilities for years to come.



The Dream ADA-128 is a 2U chassis that can accommodate up to 20 plug-in Modules. These presently include eight-channel analogue input and output Modules and an eight-channel AES3 Module. Four of the slots can accommodate a range of 64-channel Host Modules which include Pro Tools HDX and Dante Host Modules (and more to come). As well as being able to route analogue and AES3 I/O to and from Host media, full routing flexibility allows analogue to/from AES3 routing without use of Host slots, and Host-to-Host bridging.

The Dream ADA-128 contains four independent clock generators, each of which can run at different sample rates and with different sync sources. The ADA-128’s Host and I/O Modules can be dynamically assigned to these Clock Domains, allowing multiple workflows (such as separate project studios or ingest stations) to simultaneously share the resources of a single ADA-128’s resources.



Every I/O Module, as well as the unit’s built-in Routing Module, have dedicated DSP capability, which will allow a wide range of future functionality to be added by a simple software download.

The Dream ADA-128 incorporates Prism Sound’s unique Verifile technology, wherein every ADC in the system can add imperceptible metadata to its dither signal, allowing downstream processes to check that every sample in a stream is exactly as it left the ADC. This reduces the need for expensive and unreliable listening tests of every minute of every digital recording or transmission.

These and many other unique capabilities make the Dream ADA-128 the only box you will ever need, no matter what your application.


DOLBY ATMOS
The ADA-128 is set to become the centrepiece for studios worldwide. The ADA-128 allows you to meet the full Dolby Atmos channel count of 128 channels in a single 2 unit making this the most compact yet powerful solution available.



AVAILABLE I/O OPTION CARDS
The versatility of the Dream ADA-128 is only limited by your vision. Due to the flexibility and modularity of the unit your choices are unlimited with Analogue I/O, Pro-Tools, Dante and AES available from the outset. How do you want to use it?



The Line in card is an 8-channel analogue input expansion card for the Dream ADA-128

Key Features

8 high-quality analog inputs with premium analogue circuitry
Ultra-low latency state-of-the-art analogue-to-digital conversion
Expand the analog inputs on the chassis or swap out cards for customised configurations
The Line out card is an 8-channel analogue output expansion card for the Dream ADA-128

Key Features

8 high-quality analogue outputs with premium analogue circuitry
Ultra-low latency state-of-the-art digital-to-analogue conversion
Expand the analogue outputs on the chassis or swap out cards for customised configurations
The ability to support up to four digital host cards including Pro-Tools, DANTE, AES and many more in a modular form ensures the ADA-128 is a future-proof solution for all your requirements.



The ADA-128 Dante Card offers low latency, high channel count connectivity with 128 channels of bidirectional audio. The card allows high-channel digital splits between systems. A simple ethernet cable can easily connect an ADA-128 to your system, unleashing the power of audio over IP.



The modular architecture of the 16 I/O slots can also support 8 channels of AES per slot, allowing you even further flexibility to configure the ADA-128 to meet the needs of your system.


DREAM ADA-128 MIC/LINE, RAVENNA, THUNDERBOLT AND MADI CARDS COMING SOON
