Superdeal! Waldorf Iridium Keyboard m/polyphonic aftertouch

Forbehold om utsolgt!


Waldorf Iridium Keyboard.49 semi-weighted polyphonic aftertouch pressure-providing keyboard.


After introducing Iridium as a high-class synthesizer in a compact desktop form factor we take the concept further forward with the Iridium Keyboard. It’s boosting an all-new 49-key FATAR TP/8SK semi-weighted polyphonic aftertouch pressure-providing keyboard as the first such implementation of that keyboard in the world, with an expanded front panel proffering one-knob-per-function control as a workflow-raising result of this high-class synthesizer’s palpable physical makeover, also allowing for six freely-programmable Macro buttons with which users can define functions from a wide range of features for additional performance control.

Tremendous tonal changes flow freely when playing the Iridium Keyboard live since polyphonic aftertouch is transmitted individually for each note played. Performers can conceivably play and hold down any number of keys simultaneously, subsequently moving each finger individually. In other words, individual keys are affected by the pressure applied by each finger, thereby creating, for instance, individual data streams for modulation purposes, whereas with monophonic (Channel) aftertouch all notes played will respond in the same way. With a powerful Mod Matrix offering 40 independent modulation assignments, each with individual settings for Source, Amount, and Destination, Iridium Keyboard comes with powerful modulation options — just like the Iridium desktop synthesizer namesake. Notably, Iridium Keyboard is also capable of processing MPE (MIDI Polyphonic Expression) data, duly making multiple parameters of different notes separately controllable to effectively enable it to behave more like an acoustic instrumentin terms of spontaneous, polyphonic sound control.

Clearly, the 851 mm (W) x 355 mm (D) x 110 mm (H) physical dimensions of Iridium Keyboard has resulted in some marked differences to the original Iridium desktop design, with a one-knob-per-function control approach afforded by its naturally expanded front panel, albeit aided still by its industrial-grade highly-responsive touchscreen display to provide an interactive overview of the Mode page selected (via associated LFOS, OSC 1, OSC 2, OSC 3, FILTERS, MOD, and EFFECTS buttons), parameter changes, and additional information. Indeed, Iridium Keyboard also incorporates six freely-programmable Macro buttons adjacent to the Pitch and Mod (modulation) wheels with which users can define functions from a wide range of features for additional performance control, combining to further enhance its performance pedigree.

Sounds from our Quantum synthesizer flagship can conveniently be loaded into Iridium Keyboard and vice-versa.

Specifications
Waldorf Iridium Keyboard

16-voice polyphony, duo-timbral
Compatible with the Waldorf Quantum synth engine


3 Oscillators
Oscillator Modes:

Wavetable
Waveform (VA)
Particle (Sampling and Granular Sampling)
Resonator
Kernels (up to 6 sub-oscillators which can be interlinked through FM at audio rate)

3 Stereo Filters per voice
True stereo path

Dual Digital Filter:

Two filters with independable modes
12/24dB LP/HP/BP in all combinations
Nave, Largo, PPG, Quantum and StateVariable models


Digital Former:

Filter models from Waldorf Nave, Largo and PPG in HP/LP/BP/Notch
Comb filter
Bitcrusher
Drive
RingMod
StateVariable mode
Analyzer displayed in Filter view
Filter curve moves when modulated (optional)
Sophisticated filter routing options with modulatable panning and levels


Modulators:

6 Envelopes
6 LFOs
Komplex Modulator (LFO/Envelope combination with user-definable shape)


Mod Matrix:

40 slots
Fast assign mode
One additional control amount per slot
Identical Sources and Destinations can be used multiple times until the matrix is full


Keyboard:

49 keys Fatar TP/8SK keyboard
Semi-weighted sensitive keys with polyphonic aftertouch
Latch mode


Performance features:

Arpeggiator
Step sequencer with up to 32 steps for notes and parameters
Favorites screen for quick patch recall
Mod Wheel, Pitch Bend and Poly-Aftertouch
MPE capable
6 Macro buttons (six freely-programmable buttons to switch on and off functions)


Screen:

Industrial-grade highly responsive touch screen


Patches:

Over 1000 factory sounds
Capacity of 7000 patch memory slots (numbers 0000-9999 can be used)
Patches from Quantum can be loaded and vice-versa
Category filter for patch list
2GB user sample flash memory


Connections:

2x TS output
2x TS input
Headphones output with Gain control
DIN MIDI In/Out/Thru
USB Type B for MIDI connection to computers / DAWs
USB Type A for direct connection of storage devices and MIDI controllers
MicroSD slot
Kensington® lock


CV connections:

4 CV inputs plus Gate In, Trigger In, Clock In, Clock Out
Inputs can be used as modulation sources in the Mod Matrix


Overall:

Sturdy metal case
Dimensions: 851 mm wide by 355 mm depth by 110 mm height (including controls)
Weight: 14 kg
