TILBUD PROFI TX16 M-LINK, SET, 2,4 GHZ

The
personnel in our development department can boast decades of expertise,
creativity and meticulous design, and since they share a passion for RC
model sport it is no surprise when they produce something really
special. This is the new PROFI TX M-LINK tray-type transmitter – Engineered and Made in Germany.
Working
in collaboration with an internationally renowned designer, our team
created something extraordinary in terms of form and ergonomics. The
new, sophisticated and superbly elegant design raises this transmitter
to a new level of refinement. Occasionally we should allow ourselves to
aim at something above the norm in terms of quality and craftsmanship!

The PROFI TX M-LINK sets new standards in its
class, with 2.4 GHz transmission technology and numerous innovative and
pioneering features:
. Integral aerial technology (IOAT)
(Integrated Optimized Antenna Technology): integral aerial with enhanced
radiation pattern, optimised for model control: double the signal
density transmitted to the model, offering a significant enhancement in
security.
. Secure, ultra-fast signal transmission
. Clean, clearly arranged menu structure
. LiFe battery (25 hours transmitter time) with battery management

Flexible ergonomics allow the owner to fine-tune the system individually and accurately to meet his individual needs
.
Programmable speech output in three languages (German, French,
English), with 500 different words, numbers and complete sentences
. For tray-mounting, use with hand-rests or neckstrap
. Swivelling stick units
. Conveniently located side-mounted proportional controls and optional switches
. Carefully positioned digital trims for easy access

The clean, clearly arranged menu structure provides:
. Programs for power models, gliders, jets and helicopters
. QuickStart
. Languages: German, English, French
. Up to 200 model memories
. Unlimited model memory data can be saved, backed up and managed on a PC
. Up to sixteen fully proportional servo channels
. Unrestricted servo channel assignment
. 100% individual configuration of transmitter controls and switches
.
Flexible mixer structure: five mixers per model, can be used as many
times as required, seven mixer inputs per mixer, curve mixer
. Seven-point collective pitch / throttle curve for helicopters
. Three stopwatches
. Transmitter battery management: display of residual charge quantity (mAh) and residual operating time (hh : mm)
. Display of up to sixteen telemetry values
. Innovative flexible circuit board system minimises connector count for greater security
. Wireless Trainer system with individual control function transfer

Set contents:
Sixteen-channel PROFI TX16 transmitter with 200 model memories
Expanded with four switches and two rotary knobs
4000 mAh LiFe transmitter battery
RX-16-DR pro M-LINK receiver
USB lead (PC interface, charge lead)

Large, hinged, superbly legible 4? LCD monitor
Programmable speech output
Earphone socket
Illuminated “warning monitor”
Digital trims, flight phase specific
Vibration alarm
Maximum operating time 25 hours (LiFe transmitter battery)
Direct menu access buttons
Integral handle
3-D programming wheel (push / turn)
Two proportional sliders+ 2 markers
Ideally positioned sidemounted sliders and switches
Completely unrestricted installation of control elements (optional switches, buttons, rotary knobs)
USB socket (model data transfer, firmware updates, integral battery charger)
IOAT (Integrated Optimized Antenna Technology) maximum transmission power, full range,optimised radiation pattern)
