PMC6-2 New Studio Range: Hi-Definition Active 3 Way Studio Monitor(Par)

PMC6 og PMC6-2 på lager nå!

PMC6-2 New Studio Range:Hi-Definition Active 3 Way Studio Monitor(Par)

Den nye standard for studio monitorer og Dolby Atmos oppsett!

Kontakt oss for tilbud!

Vi tar også inbytte av kurante studiomonitorer!



The PMC6-2 provides main-monitor scale, depth, and dynamics, and allows mix decisions to be made quickly, with absolute certainty and without fatigue.

This 3-way active monitor speaker combines two custom 6-inch ultra-long-throw bass-drivers with our radically engineered PMC55 2-inch soft-dome mid-range unit and a precision-built one-inch soft-dome tweeter. The PMC55’s distinctive ‘N-compass’ waveguide enhances the wide dispersion and remarkable mid-range projection of the driver; in combination with the high performance of the tweeter, the result is an ultra-wide and stable image, with a smooth and natural in-room response. Each bass driver is individually powered by a cutting-edge 400W Class-D amplifier and seamlessly integrated by our sophisticated, highly accurate DSP-based crossovers. As with the PMC6, the monitor is configured using rear-panel controls or the browser-based SoundAlign? software, with comprehensive boundary and EQ options.

The PMC6-2 offers astonishing size-to-performance ratio thanks to its ATL? bass-loading technology, which results in exceptional LF extension and consistent tonal balance at all listening levels. Our Laminair? airflow technology, visible in the monitor’s hexagonal vent ducts, further reduces colouration and enhances dynamics and efficiency.

A simple upgrade path converts the PMC6-2 to a full-range XBD system; just add a PMC8.2 SUB and select XBD mode to perfectly dovetail the two units, extending the response down to 25Hz with additional headroom.


Active 3-way nearfield reference monitor with ATL? bass loading

Frequency response: 33Hz - 25kHz (- 3dB @1m full space, on-axis)

Max. cont. SPL: 109dB @1m (Half space value calculated as +3dB from full space measurement.

Un-weighted input,20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)

State-of-the-art Class-D amplifiers: HF 400W, MF 400W, LF 2x 400W

Analogue / AES3 digital input (16/24-bit, 18 -192kHz sample rate)

Digital ‘through’ output (AES3 24-bit 96kHz)

SoundAlign? network control interface for single or group EQ & settings

Sophisticated DSP crossover, driver protection, EQ, and delay/polarity options

PMC6-2 + PMC8-2 SUB = PMC6-2 XBD, with LF down to 25Hz & increased headroom

Ceiling-mount yoke allows suspension in multi-channel or immersive systems


TypeActive 3-way nearfield reference monitor with ATL? bass loading

Drive Unit ComplementLF 2 x PMC 150mm (6”) studio 6 drivers
MF PMC 55mm (2”) soft dome mid-range
HF PMC 27mm (1”) soft dome tweeter Effective ATL? Length2m (6.6ft)

Frequency Response33Hz - 25kHz (- 3dB) (@1m full space, on-axis) Sensitivity+4dBu input signal = 98dB SPL @ 1m

Max continuous SPL 109dB @1m (Half space value calculated as +3dB from full space measurement.

Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)

Max Peak SPL121dB @1m (Half space value calculated as +3dB from full space measurement.

Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)

DirectivityH +/-50 degrees V +60/-40 degrees (-6dB off axis @10kHz)

InputXLR switchable between analogue & digital AES3 Analogue input - +20/+24dBu max.

input level (selectable) - 22K ohm input impedance

Digital input - 16/24-bit AES3 signal, left, right or left + right - 18 - 192kHz Sample Rate - 110 ohm input impedance

Expansion card slot - For future connectivity upgrades

OutputXLR digital AES3 (fixed 24-bit @ 96kHz)

NetworkRJ45 for use with PMC SoundAlign web interface Features

Level Trim (+/-10dB) High-pass filter (20 - 200Hz, 12dB/Oct) Delay (0 - 30mS)

Phase (normal or inverted) LF & HF shelving filters (20Hz - 20kHz, +/- 10dB, Q 0.707) Parametric EQ (5 bands, 20Hz - 20kHz, +/- 10dB) User presets (3 + factory defaults) Latency2.4mS

Amplifier power per channel

LF 2 x 400Wrms

MF 1 x 400Wrms

HF 1 x 400W

rms Mains100 - 240VAC auto-switching, 50-60Hz (IEC C14)

Power consumption (idle)50W Power consumption (max)1500W Cabinet dimensionsH 400mm (15.7”) W 430mm (16.9”) D 372mm (14.6”)

Weight21.3kg (47lbs) each


Available Finishes: Studio black
