TAMIYA LANDFEEDER QUADTRACK (TT-02FT)

Landfreeder Quadtrack. Kommer som byggesett.

TBLE-04S fartskontroller og 540 motor medfølger.

Må kompletteres med:

Radio og mottaker
Servo
NiMH eller LiPO batteri
Batterilader
PS Lakk
Anbefales:

Kulelagre: 64stk 850 (5x8x2.5), 8stk 1050 (5x10x4), 12stk 1150 (5x11x4), 8stk 1280 (8x12x3.5)


Fra produsenten:

Length: 425mm. Image shows painted and assembled kit.

On the Right Track
This assembly kit creates an R/C model off-road truck which shows high performance on poor surfaces. Its chassis is based upon the TT-02 shaft-driven 4WD unit, with superlative traction from its four individual tracks that helps it plow through snow, sand, mud and other testing conditions. Its 1980s pick-up truck style body is molded in polycarbonate, with fog lamps, grille guard and roll bar recreated using separate metal-plated parts. A polycarbonate chassis cover and wheel well liners help prevent dirt and the like from getting into the chassis and potentially causing damage.


Tracked 4WD Fun: the TT-02FT Chassis
The TT-02FT chassis uses the shaft-driven TT-02 as a base, with track units in place of the four wheels. Each of the track units is attached to upper and lower suspension arms, and is powered via a drive sprocket that attached to the chassis drive shaft; they swing to allow superior contact with the running surface, and feature a sprung roller to allow easier negotiation of smaller obstacles. Plenty of ground clearance is on offer, too. Tracks are a plastic assembly type design with metal link pins, and give minimal power loss from friction for a smooth drive, even at lower speeds. Two types of link are included in the kit – standard, and jutting grouser designs – and can be used in tandem to customize your model’s grip. The chassis features a CR-Tuned motor as standard.
