IKEDA 9Gss Pick-Upen

Ikeda 9Gss UTSOLGT, men kommer snart inn igjen.

Kun produsert 200 stk.

Uhørt dynamikk og oppløsning.

Ring for et godt J U L E - tilbud.
Det blir inkludert noen direktegraverte LP-plater med IKEDA elementer som blir bestilt før Julaften i år - 2023.




The internal frame construction is made of the upper base (A) and the center pillar base (B) that are independently constructed and precisely assembled, instead of the usual construction of a single integrated design. As for the center pillar base, a special anti-vibration alloy which has the highest ability and the most superior to the absorbability for vibration and noise is adopted, so that the outline and imaging of sound will become much clearer.

As for the upper base, the most strong and solid Titanium is precisely CNC machined from the block, then buffed and polished manually one by one. Finally, the special process and final finish, 24K Gold plating of 5 microns thickness on top of Rhodium plating is applied. In addition, the outer body covering the internal mechanism and components is cut out from solid aluminum, and then processed by a hard buffing manually one by one. Then as a final process, the special surface treatment of the body 24K Gold plating of 5 microns on top of silver plating of 5 microns on the surface is applied. This kind of surface treatment is mainly applied for brass instruments in order to secure the best sound reverberation. Thanks to this treatment, the sound will become brilliant, elegant and distinctive.



https://m.youtube.com/watch?v=1LKEdM_j1aM

Specifications of IKEDA 24K Gold plated “9Gss”

- Electromagnetic Generator: Moving Coil (MC)
- Output Voltage: 0.3 mVrms (1kHz 35.4 mm/sec. at 45 peak)
- Coil Impedance: 3.0 ohms (1kHz)
- Appropriate Stylus Force: 2.0 grams 0.1 grams
- Frequency Response Range: 10Hz ~ 45kHz
- Channel Separation: Over 30 dB (1kHz)
- Channel Balance: Within 1.0 dB (1kHz)
- Compliance: 10 x 10 -6cm/dyne
- Stylus Chip: Solid pure square diamond
- Cantilever: Made of pure Boron
- Weight: 14.0 grams



.
